Mindman MVSZ-100 series

Mindman MVSZ-100-4E2 Solenoid Valve, 5/2-Way Double Solenoid (Body Ported)

SKU MVSZ-100-4E2-DC24-LJ
by Mindman
$138.84 - $173.13
$138.84
$138.84 - $173.13
$138.84
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman MVSZ-100 series 5/2-way double solenoid solenoid valve (body ported).

Electrical connection: LJ - plug on side with flying leads (JPC type), 500mm.

Price varies by coil voltage.

Specifications

Bore No. M5
Port size M5×0.8
No. of port 5
No. of position 2
Medium Air
Operating pressure range 0.15~0.7 MPa
Proof pressure 1 MPa
Flow 255 l/min
Effective orifice 4.7 mm² (0.26 Cv)
Response time 17 ms
Max. operating frequency 5 Hz
Ambient temperature ＋5~＋50℃
Voltage AC110V, AC220V (50/60)Hz, DC6/12/24V
Power consumption AC=1.6 / 2.5VA, DC=0.55W (LED indicator)
Available voltage range ±10%
Insulation class B class
Weight 40 g, 53 g
Series Mindman MVSZ-100
