Mindman MVSF-100 series

Mindman MVSF-100M-4E2 Solenoid Valve, 5/2-Way Double Solenoid (Manifold Type)

SKU MVSF-100M-4E2-DC6-LJ
by Mindman
$121.28 - $131.10
$131.10
$121.28 - $131.10
$131.10
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman MVSF-100 series 5/2-way double solenoid solenoid valve (manifold mount).

Electrical connection: LJ - plug on side with flying leads (JPC type), 500mm.

Price varies by coil voltage.

Specifications

Bore No. M3
Port size M3×0.5
No. of port 3,5
No. of position 2
Medium Air
Operating pressure range 0.15~0.7 MPa
Effective orifice mm² (Cv) P→A/B: 1.0 (0.06)
Response time 12 ms
Max. operating frequency 5 Hz
Ambient temperature +5~+50℃
Lubrication Not necessary
Voltage AC110, AC220V(50/60)Hz, DC6/DC12/DC24V
Power consumption AC=1.6 / 2.5VA,DC=0.55W (LED indicator)
Available voltage range ±10%
Insulation class B class
Weight 25g ~ 44g
Series Mindman MVSF-100
