Mindman MVSF-100 series

Mindman MVSF-100 Manifold 5B - 5 Port, Body ported type

SKU MVSF-100-5B1
by Mindman
$7.03 - $25.84
$7.03
$7.03 - $25.84
$7.03
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman manifold for MVSF-100 solenoid valves (Body ported type (5B/3B)).

Select the number of stations.

Specifications

Bore No. M3
Port size M3×0.5
No. of port 3,5
No. of position 2
Medium Air
Operating pressure range 0.15~0.7 MPa
Effective orifice mm² (Cv) P→A/B: 1.0 (0.06)
Response time 12 ms
Max. operating frequency 5 Hz
Ambient temperature +5~+50℃
Lubrication Not necessary
Voltage AC110, AC220V(50/60)Hz, DC6/DC12/DC24V
Power consumption AC=1.6 / 2.5VA,DC=0.55W (LED indicator)
Available voltage range ±10%
Insulation class B class
Weight 25g ~ 44g
Series Mindman MVSF-100
