Mindman MVSE-600 series

Mindman MVSE-600-4E1 Solenoid Valve, 5/2-Way Single Solenoid (Body Ported)

SKU MVSE-600-4E1-AC220
by Mindman
$296.66 - $299.85
$296.66
$296.66 - $299.85
$296.66
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman MVSE-600 series 5/2-way single solenoid solenoid valve (body ported).

Select the coil voltage, electrical connection and port thread; the full Mindman ordering code is shown as the SKU.

Ordering code format: MVSE-600-4E1-[Voltage]-[Connection]-[Thread]

Specifications

Body width 60 mm
Bore No. 20A, 25A
Port size 3/4, 1
No. of port 5
No. of position 2
Medium Air
Operating pressure range 0.2~0.7 MPa
Proof pressure 1 MPa
Flow 5227 l/min(20A), 5440 l/min(25A)
Effective orifice 20A: 96 mm² 、25A: 100 mm²
Response time 80 ms
Ambient temperature －5~＋50℃ (No freezing)
Voltage AC110V, AC220V (50/60)Hz, DC24V
Power consumption AC=13/11VA, DC=10W
Available voltage range ±10%
Insulation class H class
Weight 1817g, 2102g
Series Mindman MVSE-600
