Mindman MVSD1-180-5P Blocking Plate (5 port)

Specifications

Body width 18 mm
Bore No. 6A
Port size 1/8
No. of port 5
No. of position 2, 3
Medium Air
Operating pressure range 0.15~0.8 MPa, 0.2~0.7 MPa (5/3)
Proof pressure 1 MPa
Flow 653 l/min, 490 l/min (5/3)
Effective orifice 12 mm², 9mm² (5/3)
Response time 30 ms
Ambient temperature －5~＋50℃ (No freezing)
Voltage AC110V, 220V (50/60)Hz, DC24V
Power consumption AC=3.7/3.1VA, DC=2.9W
Available voltage range ±10%
Insulation class F class
Weight 124g~190g
Series Mindman MVSD1-180
