Mindman MVSC-460 series

Mindman MVSC-460-3E1-NC Solenoid Valve, 3/2-Way Single Solenoid, Normally Closed (Body Ported) - External Pilot (LP)

SKU MVSC-460-3E1-NC-AC220-LP
by Mindman
$64.90 - $64.90
$64.90
$64.90 - $64.90
$64.90
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman MVSC-460 series 3/2-way single solenoid solenoid valve (body ported).

Select the coil voltage, electrical connection and port thread; the full Mindman ordering code is shown as the SKU.

Ordering code format: MVSC-460-3E1-NC-[Voltage]-[Connection]-[Thread]

Specifications

Bore No. 15A
Port size 1/2
No. of port 3, 5
No. of position 2, 3
Medium Air
Operating pressure range 0.2~0.8 MPa, 0.3~0.8 MPa
Operating pressue (LP) 0~0.8 MPa
Pilot pressure range (LP) (0.34×P(*1)+0.1)~0.5 MPa
Proof pressure 1 MPa
Effective orifice 60 mm², 50 mm², 30 mm²
Reponse time 50 ms
Ambient temperature －5~＋50℃ (No freezing)
Voltage AC110V, 220V, 24V (50/60)Hz, DC24V, 12V
Power consumption-Standard AC=4.8/4.4VA, 6/4.9VA, 6.7/5.4VA, DC=2W, 2.5W
Power consumption-Power saving DC24V=Start: 2W(*2) Power saving: 0.5W
Available voltage range ±10%
Insulation class F class
Weight Valve: 325g, 455g, 339g, 464g, 525g; Manifold: 131n+84g, 145n+91g (n: Stations)
Remark *1. P: Operating pressure; *2. Power saving covert time 100ms.
Series Mindman MVSC-460
