Mindman MTA series

Mindman MTAD-63 Swing Clamp Cylinder, ø63 mm

SKU MTAD-63-CW-90
by Mindman
$509.67 - $734.01
$509.67
$509.67 - $734.01
$509.67
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman MTAD series pneumatic swing clamp cylinder, ø63 mm bore, 90° standard rotation, standard clamping arm.

Select the options below; the full Mindman ordering code is shown as the SKU (MTAD[L]-63[M]-[CW/CCW]-90[-FA/FC]).

Manifold types FA / FC are standard clamping stroke without magnet.

Price is the Mindman list price.

Specifications

Acting type Double acting
Tube I.D. (mm) MTAS (Single side clamping arm):25,32,40,50,63, MTAD (Double sides clamping arm):32,40,50,63
Medium Filtered air with or without lubrication
Operating pressure range 0.1~1 MPa
Max. pressure 1.47 MPa
Material of cylinder barrel Anodised aluminum alloy
Standard angle of rotation 90°±2°(Angle of 0°, 45°and 60°are optional)
Rotating direction Clockwise or counter clockwise
Sensor switch LN40R
Series Mindman MTA
