MP20 / MP25 / MP23 series (Pressure Switch / Digital Pressure Gauge).

Positive, Display only

Specifications

Operating pressure range Compound: －100.0~100.0 kPa; Positive: －0.10 ~ 1.00 MPa
Medium Air, Non-corrosive gases,incombustible gases
Proof pressure Compound: 300 kPa, Positive: 1.5 MPa
Power supply voltage 12 to 24VDC ±10%, Ripple (P-P) 10% or less
Current consumption ≦55mA
7 segment LCD display 3½ digit LED display (Red) (Sampling rate: 5 times/sec.)
Indicator accuracy ≦±2% F.S. ±1 digit (ambient temperature: 25 ±3℃)
Enclosure IP40
Ambient temp. range Operation: 0 ~ 50℃,storage:-20 ~ 60℃ (No condensation or freezing)
Ambient humidity range Operation/Storage: 35 ~ 85% RH (No condensation)
Withstand voltage 1000VAC in 1-min (between case and lead wire)
Insulation resistance 50Mohm min. (at 500VDC M, between case and lead wire)
Vibration Total amplitude 1.5mm,10Hz-55Hz-10Hz scan for 1 minute, two hours each direction of X,Y and Z
Shock 980m/s² (100G),3 times each in direction of X,Y and Z
Temperature characteristic ≦2% F.S. of detected pressure (25℃) at temp. Range of 0~50℃
Lead wire ø4 Oil-resistance cable (PVC) - 26 AWG (0.15 mm²) - 2 cores
Weight Appro 102 g (with 2-meter lead wire)
Series Mindman MP23
