Mindman METFB series

Mindman METFB-32 Belt-Driven Electric Slider (without motor)

SKU METFB-32N-100BW-(M40/P20/P40/S42/B42)
by Mindman
$1,003.52 - $3,017.80
$1,003.52
$1,003.52 - $3,017.80
$1,003.52
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Mindman METFB series belt-driven electric slider, size 32, supplied without motor.

Select the options below; the full Mindman ordering code is shown as the SKU (METFB-32[guide]-[stroke][motor position]-[flange]).

Codes shown in brackets in the SKU are chosen on this page and printed on your order.

Accessories: ETFB32 mounting brackets · RZ-EB2 sensor set · AK-EB2 accessory kit

Price is the Mindman list price.

Specifications

Position repeatability (mm/rev) ±0.05
Lead (mm/rev) 25: 50; 32: 72; 40: 72
Belt pitch (mm) 25: 2; 32: 3; 40: 3
Stroke (mm) 25: 100~1000/50 pitch; 32: 100~2000/50 pitch; 40: 100~2000/50 pitch
No-load torque (N.m) 25: 0.1; 32: 0.2; 40: 0.6
Sensor switch RLT
Power output / size 25: AC servo: 50W, 100W, Step: □42; 32: AC servo: 200W, 400W, Step: □42; 40: AC servo: 200W, 400W, Step: □56
Max. speed (mm/s) *1 25: AC servo: 1500, Step: 500; 32: AC servo: 2400, Step: 720; 40: AC servo: 2400, Step: 720
Work load *2,3 25 Horizontal: AC servo: 1.7kg, 3.5kg, Step: 3.2kg; 32 Horizontal: AC servo: 5kg, 10kg, Step: 3.5kg; 40 Horizontal: AC servo: 7.5kg, 15kg, Step: 13kg
Remark *1. Acceleration and deceleration value is set 0.5 second.; *2. The operating speed under work load is less than maximum speed.; *3. Not available for vertical condition.
Series Mindman METFB
