Mindman MAFR402 series

Mindman MAFR402-20A Filter Regulator

SKU MAFR402-20A-NPT
by Mindman
$107.91 - $107.91
$107.91
$107.91 - $107.91
$107.91
Availability:
In stock
Availability:
In stock
Availability:
In stock

MAFR (F.R. unit).

Port thread: choose NPT, Rc (BSPT) or G (BSPP). The thread code is the last part of the Mindman ordering code (blank = Rc).

Specifications

Bore No. 10A, 15A, 20A
Port size 3/8, 1/2, 3/4
Medium Air
Operating pressure range (※) 0.05~1 MPa
Proof pressure 1.5 MPa
Regulated pressure range 0.05~0.85 MPa
Ambient temperature －5~＋60℃ (No freezing)
Filter element Standard:40 μm Option:5μm,20 μm
Attachment Pressure gauge, bracket
Weight 1186 g
Remark ※ Standard unit contains semi-auto-drain function when; operating pressure below 0.05 MPa.
Series Mindman MAFR402
