Mindman MACT402 series

Mindman MACT402-10A Air Preparation Unit

SKU MACT402-10A-NPT
by Mindman
$180.08 - $180.08
$180.08
$180.08 - $180.08
$180.08
Availability:
In stock
Availability:
In stock
Availability:
In stock

MACC / MACT (F.R.L.unit).

Port thread: choose NPT, Rc (BSPT) or G (BSPP). The thread code is the last part of the Mindman ordering code (blank = Rc).

Specifications

Components MAF402, MAR402, MAL402
Bore No. 10A, 15A, 20A
Port size 3/8, 1/2, 3/4
Medium Air
Operating pressure range (※) 0.05~1 MPa
Proof pressure 1.5 MPa
Regulated pressure range 0.05~0.85 MPa
Ambient temperature －5~＋60℃ (No freezing)
Filter element Standard:40 μm Option:5 μm,20 μm
Lubricating oil capacity 180c.c
Min. flow for oil drip 200 l/min
Recommended lubricating oil Turbine oil ISO-VG32
Attachment Pressure gauge, bracket
Weight 2392 g
Remark ※ Standard unit contains semi-auto-drain function when; operating pressure below 0.05 MPa.
Series Mindman MACT402

No additional information at this time.
