Mindman MACT300L series

Mindman MACT300L-10A Air Preparation Unit

SKU MACT300L-10A-NPT
by Mindman
$111.30 - $111.30
$111.30
$111.30 - $111.30
$111.30
Availability:
In stock
Availability:
In stock
Availability:
In stock

MACC / MACT (F.R.L.unit).

Port thread: choose NPT, Rc (BSPT) or G (BSPP). The thread code is the last part of the Mindman ordering code (blank = Rc).

Specifications

Components MAF300L,MAR301,MAL300L
Bore No. 8A,10A
Port size 1/4, 3/8
Medium Air
Operating pressure range (※) 0.05~1 MPa
Proof pressure 1.5 MPa
Regulated pressure range 0.05~0.85 MPa
Effective orifice 8A:32mm²,10A:34mm²
Ambient temperature －5~＋60℃ (No freezing)
Filter element Standard:5μm Option:40μm
Lubricating oil capacity 65c.c
Min. flow for oil drip 8A:50 l/min,10A: 60 l/min
Recommended lubricating oil Turbine oil ISO-VG32
Attachment Pressure gauge (PG-40), T-type bracket
Weight 959 g
Remark ※1.Standard unit contains semi-auto-drain function when; operating pressure below 0.05 MPa.; ※2.Choose auto-drain FMRF300,the pressure range is 0.15~1 MPa.
Series Mindman MACT300L
