Mindman MACT300-10A Air Preparation Unit

Name: Mindman MACT300-10A Air Preparation Unit
Brand: Mindman
SKU: MACT300-10A-NPT
Price: 97.1 USD
Availability: InStock

SKU MACT300-10A-NPT

by Mindman

$97.10 - $97.10

$97.10

$97.10 - $97.10

$97.10

Availability:

In stock

Availability:

In stock

Availability:

In stock

Quantity

Description

MACC / MACT (F.R.L.unit).

Port thread: choose NPT, Rc (BSPT) or G (BSPP). The thread code is the last part of the Mindman ordering code (blank = Rc).

Components	MAF300,MAR301,MAL300
Bore No.	8A,10A
Port size	1/4, 3/8
Medium	Air
Operating pressure range (※)	0.05~1 MPa
Proof pressure	1.5 MPa
Regulated pressure range	0.05~0.85 MPa
Effective orifice	8A:32mm², 10A:34mm²
Ambient temperature	－5~＋60℃ (No freezing)
Filter element	Standard:5μm Option:40μm
Lubricating oil capacity	55c.c
Min. flow for oil drip	8A:50 l/min,10A:60 l/min
Recommended lubricating oil	Turbine oil ISO-VG32
Attachment	Pressure gauge (PG-40), T-type bracket
Weight	944 g
Remark	※ Standard unit contains semi-auto-drain function when; operating pressure below 0.05 MPa.
Series	Mindman MACT300
