Mindman MACP300 series

Mindman MACP300-8A Air Preparation Unit

SKU MACP300-8A-NPT
by Mindman
$77.60 - $77.60
$77.60
$77.60 - $77.60
$77.60
Availability:
In stock
Availability:
In stock
Availability:
In stock

MACP (F.R.L.unit).

Port thread: choose NPT, Rc (BSPT) or G (BSPP). The thread code is the last part of the Mindman ordering code (blank = Rc).

Specifications

Components MAFR300, MAL300
Bore No. 8A,10A
Port size 1/4, 3/8
Medium Air
Operating pressure range (※) 0.05~1 MPa
Proof pressure 1.5 MPa
Regulated pressure range 0.05~0.85 MPa
Ambient temperature －5~＋60℃ (No freezing)
Filter element Standard:5μm Option:40μm
Lubricating oil capacity 55c.c
Min. flow for oil drip 50 l/min,60 l/min
Recommended lubricating oil Turbine oil ISO-VG32
Attachment Pressure gauge (PG-40), T-type bracket
Weight 724 g
Remark ※ Standard unit contains semi-auto-drain function when; operating pressure below 0.05 MPa.
Series Mindman MACP300
