XTC5400-CU - Counter / Timer

7 Segment LED Display


Features

• Dual Display, 4 digit, 7 segment LED

• 2 Setpoints

• Programmable Input Scaling

• Down Counting for Timer, Up / Down Counting for Counter

Analog / Digital Protection Relays

Protection
Altech is pleased to offer a variety of protection relays covering:

  • Phase Monitoring

  • Voltage Monitoring

  • Current Monitoring

  • Frequency Monitoring

Current Leakage / Ground Fault Monitoring Protection relays help to maintain systems and ensure that proper action is taken when a fault is detected. Such functions help to preserve productivity and operational effectiveness of integral components.

Specifications

Part Number XTC5400-CU
Supply Voltage 90-270V AC/DC
LED Indication LED 1: Relay 1, LED 2: Relay 2, LED 3: sec., LED 4: Min., LED 5: Hrs.
Process Contollers - Input Voltage 85-270V AC/DC (50/60Hz)
Input Measurement NPN/PNP
Main Output 2 SPST - 2NO - 5 @ 230V AC
Reset Front, Remote/ Power interruption (programmable)
Power Consumption 5VA max
Operating Temperature 0 to 50°C (32 to 122°F)
Storage Temperature -20 to 75°C (-4 to 167°F)
Humidity (Non-Condensing) 95% Relative Humidity
Weight 175 grams (.385 lbs)
Display Type 7 Segment LED Display
Digits 2 rows of 4 digits
Set Points 2
Modes Timer : ON delay /Interval /Cyclic On first / Cyclic OFF first / Batch / Counter : ON delay /Interval / Auto reset, Time pulse repeat , Batch
Sensor Supply Inbuilt, 12V DC, 30mA
Input Type Voltage Pulse (3-30V DC) from proximity, switches, encoders, solid state devices, potential free contact
Input Speed A) 3Hz, B) 30Hz, C) 5kHz
Counting Direction Up, Down, Bidirectional, Quadrature
Memory 10 years
Scale Factor 0.00001-9.99999 X 10n , n equals -3, -2, -1, 0, 1, 2
Rate +/-.05% of Full Scale or 50m sec.
Time Ranges 0-99.99 sec 0-999.9 sec/min/hr 0-9999 sec/min/hr 0-99:59 min: sec 0-99:59 hr:min
Counter Range -999 to 9999 counts
