Altech MV1521-5,08-V-L PCB Terminal Block, 5.08mm, 21 Pole, Front Wire, Green

Altech MV1521-5,08-V-L PCB Terminal Block, 5.08mm, 21 Pole, Front Wire, Green

SKU MV1521-5,08-V-L
by Altech
$10.84 - $10.84
$10.84
$10.84 - $10.84
$10.84
Availability:
In stock

PCB Term Blk, 5.08mm, 21 Pole, Front wire, green

13.5A, 300V, 16-30AWG, 10.6mm height, no dovetail

Specifications

Part Number MV1521-5,08-V-L
Color Green
PCB Type Fixed
Pin Spacing 5.08mm
Connection Type Cage Clamp
Series MV15
Poles 21
Min Wire Size AWG 30
Max Wire size stranded AWG 16
Max Wire size solid AWG 16
Min Wire size sqmm 0.25
Max Wire size stranded sqmm 1.50
Max Wire size solid sqmm 1.50
Current Rating UL 13.5A
Voltage Rating UL 300V
Current Rating IEC 13.5A
Voltage Rating IEC 250V
Height 10.60mm
Length 106.68mm
Number Rows 1
Mounting Vertical
Wire Entry 0°
PCB Layout Linear Center
Solder Pin Length 3.70mm
PCB Hole Size 1.30mm
Mounting Type Wave soldering
Marking NA
Packaging Carboard Box
Weight (kg) 0.017976
Country of Origin Italy
Tariff Code 8536.69.4040
Standard Pack 50
