PCB Term Blk, 10.16mm, 9 Pole, Front wire, green

57A, 300V, 6-30AWG, 29.0mm height, modular

Specifications

Part Number MV-1009
Color Green
PCB Type Fixed
Pin Spacing 10.16mm
Connection Type Cage Clamp
Series MV10
Poles 9
Min Wire Size AWG 30
Max Wire size stranded AWG 6
Max Wire size solid AWG 6
Min Wire size sqmm 0.25
Max Wire size stranded sqmm 10.0
Max Wire size solid sqmm 16.0
Current Rating UL 57A
Voltage Rating UL 600V
Current Rating IEC 70A
Voltage Rating IEC 750V
Height 29.00mm
Length 91.44mm
Number Rows 1
Mounting Vertical
Wire Entry 0°
PCB Layout Linear Center
Solder Pin Length 4.50mm
PCB Hole Size 1.70mm
Mounting Type Wave soldering
Marking NA
Packaging Carboard Box
Weight (kg) 0.073800
Country of Origin Italy
Tariff Code 8536.69.4040
Standard Pack 50

Documents

No additional information at this time.
