GMD-12M-10-DC24V MC Series - MINI Contactors

Suitable for the switching and protection of motors, capacitor banks, lights, and other AC circuit applications. Thermal style overload relays can be easily attached for motor protection and various accessories are also available including coil surge suppression, timer unit, auxiliary contacts. Featuring low power consumption type coils which can often be driven directly from a PLC without additional output relays.

Specifications

Part Number GMD-12M-10-DC24V
MC MINI Contactor Type 12A
MC MINI Number of Poles 3 NO main Contacts, 1 auxilliary Contact
MC MINI NEMA size 00
MC MINI Standard Auxilaries 1NO
MC MINI Coil Voltage AC/DC Coil 24V
MC MINI Frequency NA
MC MINI HP Continuous Current 20A
MC MINI Contactor HP Rating 110~120V 1
MC MINI Contactor HP Rating Single Phase 220~240V 2
MC MINI Contactor HP Rating Three Phase 240V 3
MC MINI Contactor HP Rating Three Phase 480V 7.5
MC MINI Contactor HP Rating Three Phase 600V 10
MC MINI Terminal Type Screw Clamp

Documents

No additional information at this time.
