PCB Term Blk, 9.52mm, 8 Pole, Top wire, green

30A, 300V, 10-30AWG, 12.5mm height, modular

Specifications

Part Number MV498-9,52-H
Color Green
PCB Type Fixed
Pin Spacing 9.52mm
Connection Type Cage Clamp
Series MV49
Poles 8
Min Wire Size AWG 30
Max Wire size stranded AWG 10
Max Wire size solid AWG 10
Min Wire size sqmm 0.25
Max Wire size stranded sqmm 6.00
Max Wire size solid sqmm 6.00
Current Rating UL 30A
Voltage Rating UL 300V
Current Rating IEC 32A
Voltage Rating IEC 750V
Height 12.50mm
Length 76.16mm
Number Rows 1
Mounting horizontal
Wire Entry 90°
PCB Layout Linear
Solder Pin Length 4.50mm
PCB Hole Size 1.30mm
Mounting Type Wave soldering
Marking NA
Packaging Carboard Box
Weight (kg) 0.021896
Country of Origin Italy
Tariff Code 8536.69.4040
Standard Pack 100
