Sensor-Actuator Cordset, Double-ended, M8 A-code 4-pin Straight Female, to M8 A-code 3-pin Straight Male, with PUR grey jacket 0.25mm² (24 AWG) 5 million bending cycles cable, 10 m

CO8.4-10-C8.3/P

SKU CO8.4-10-C8.3/P
by ELCO Industrial Automation

Sensor-Actuator Cordset, Double-ended, M8 A-code 4-pin Straight Female, to M8 A-code 3-pin Straight Male, with PUR grey jacket 0.25mm² (24 AWG) 5 million bending cycles cable, 10 m

$27.84 - $27.84
$27.84
$27.84 - $27.84
$27.84
Availability:
In stock

Sensor-Actuator Cordset, Double-ended, M8 A-code 4-pin Straight Female, to M8 A-code 3-pin Straight Male, with PUR grey jacket 0.25mm² (24 AWG) 5 million bending cycles cable, 10 m

Specifications

Wire insulation material PP
Coating contact material Gold plated copper
Drag chain 5 million bending cycles
Nut/bolt material Zinc die casting
Cable jacket color grey
The head material TPU
LED indicator NO
Material contact TPU
Wire insulation color BN, WH, BU, BK
Cable jacket material PUR

No additional information at this time.

Downloads

CE ELCO_signal connector_CE.pdf
UL ELCO_UL-M8.pdf
Datasheet ELCO_M8 Double-ended connector DataSheet_EN.pdf
