Altech AIS30N15AN024-Q65 M30 Non-Flush Mount Cylindrical Sensor, DC - 3 WIRE-STANDARD

Altech AIS30N15AN024-Q65 M30 Non-Flush Mount Cylindrical Sensor, DC - 3 WIRE-STANDARD

SKU AIS30N15AN024-Q65
by Altech
$80.98 - $80.98
$80.98
$80.98 - $80.98
$80.98
Availability:
In stock

AIS30N15AN024-Q65 - M30 Non-Flush Mount Cylindrical Sensor, DC - 3 WIRE-STANDARD

Brass, Nickel Plated (BN), Cylindrical, Threaded, 10-30V DC, 250mA, LED for Output Energized

• IEC (529) IP67 (NEMA 1, 3, 4, 6, 12, 13) Protection

• Short Circuit Protection

• Overload Protection

• Reverse Polarity Protection

• Wire Break Resistance

• Transient Voltage Protection

• Temperature Range: -25 to 70°C (-13 to 158°F)

Fixed Cable

PVC 2m (6ft. 6in.). For other cable lengths and/or PUR cable, please consult Altech. M8 is supplied with stainless steel locknuts and M12 is supplied with brass, nickel plated locknuts.

Specifications

Part Number AIS30N15AN024-Q65
Sensing Distance 10mm (.39 in.)
Cable or Connector Style 65
Ripple Voltage ≤ 10%
Voltage Range 10-30V
No-Load Current ≤ 15mA
Sensor -Max. Load Current 250 mA
Voltage Drop Across Sensor ≤ 2.5V
Max. Leakage Currrent ≤ 1 μA
Switching Frequency 300 Hz
Hysterisis ≤1.5mm
Temperature Drift ≤±30μm/K
Repeatability ≤1.0mm
Output Configuration NPN - Normally Open / Complementary NO/NC

Documents

No additional information at this time.
