Profibus Cordset, Double-ended, M12 B-coded 2-pin Male Straight - M12 B-coded 2-pin Female Straight, PUR Lake Blue 2x 24 AWG 5 million bending cycles Cable, 10m

BB5S30PP8M100

SKU BB5S30PP8M100
by ELCO Industrial Automation

Profibus Cordset, Double-ended, M12 B-coded 2-pin Male Straight - M12 B-coded 2-pin Female Straight, PUR Lake Blue 2x 24 AWG 5 million bending cycles Cable, 10m

$185.04 - $185.04
$185.04
$185.04 - $185.04
$185.04
Availability:
In stock

Profibus Cordset, Double-ended, M12 B-coded 2-pin Male Straight - M12 B-coded 2-pin Female Straight, PUR Lake Blue 2x 24 AWG 5 million bending cycles Cable, 10m

Specifications

Cable length 10 m
Shielded/Unshielded YES
Connector type M12
Number of contacts 5
Coding B-code
Shape Straight
Gender Female-Male
Rated voltage 250 V AC/DC
Rated current 4 A
The head material TPU
Coating contact material Gold-plated copper
Cable jacket material PUR
Cable jacket color blue

No additional information at this time.

Downloads

CE ELCO_Communication Connector_CE.pdf
UL ELCO_UL-Profibus Connector.pdf
Datasheet ELCO_Profibus Connector_DataSheet_EN.pdf
3D Drawing ELCO_BB5S30PPXMXXX.stp
