Photoelectric Sensor, OSM70-Series, Defused with BGS, Infrared laser + Laser indication, Operating range 4 m, Push-Pull, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 20…50 Hz, IP67, M12 4-pin connector

OSM70-AKL4000VB6Q

SKU OSM70-AKL4000VB6Q
by ELCO Industrial Automation

Photoelectric Sensor, OSM70-Series, Defused with BGS, Infrared laser + Laser indication, Operating range 4 m, Push-Pull, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 20…50 Hz, IP67, M12 4-pin connector

$138.96 - $138.96
$138.96
$138.96 - $138.96
$138.96
Availability:
In stock

Photoelectric Sensor, OSM70-Series, Defused with BGS, Infrared laser + Laser indication, Operating range 4 m, Push-Pull, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 20…50 Hz, IP67, M12 4-pin connector

Specifications

Connection type M12, 4-pin
Light source Infrared laser + laser indication / Class 1
Spot size 14 × 7 cm @ 4 m
Connection Connector
Output type Push-pull
Output status L.O + D.O
Switching frequency 20 ... 50 Hz
Supply voltage 10 ... 30 V DC
Anti-ambient light ≤ 10000 lux
Detection method TOF BGS Di

No additional information at this time.

Downloads

CE ELCO_OSM70_CE.pdf
Datasheet ELCO_OSM70_DataSheet_EN.pdf
Datasheet ELCO_OSM70_DataSheet_CN.pdf
3D Drawing ELCO_OSM70-AKL4000VB6Q.stp
Manual ELCO_OSM70-AKL4000VB6Q_Manual.pdf
