Photoelectric Sensor, OS50-Series, Diffused, Red beam, Operating range 1 m, NPN, L.O + D.O, 10…30V DC, -25…55°C, Switching frequency 800 Hz, IP67, M12 4-pin connector

OS50-K1000VN6Q

SKU OS50-K1000VN6Q
by ELCO Industrial Automation

Photoelectric Sensor, OS50-Series, Diffused, Red beam, Operating range 1 m, NPN, L.O + D.O, 10…30V DC, -25…55°C, Switching frequency 800 Hz, IP67, M12 4-pin connector

$39.28 - $39.28
$39.28
$39.28 - $39.28
$39.28
Availability:
In stock

Photoelectric Sensor, OS50-Series, Diffused, Red beam, Operating range 1 m, NPN, L.O + D.O, 10…30V DC, -25…55°C, Switching frequency 800 Hz, IP67, M12 4-pin connector

Specifications

Sensing range 1000 mm
Light source Red LED
Spot size 3 cm @ 1 m
Output type NPN
Detection method Diffused
Output status L.O + D.O
Switching frequency 800 Hz
Supply voltage 10 ... 30 V DC
Load current ≤ 200 mA
Connection type M12, 4-pin
IP rating IP67
Connection Connector
Housing material PBT

No additional information at this time.

Downloads

CE ELCO_OS50_CE.pdf
Datasheet ELCO_OS50_DataSheet_EN.pdf
Datasheet ELCO_OS50_DataSheet_CN.pdf
3D Drawing ELCO_OS50-K1000VN6Q.stp
Manual ELCO_OS50-K1000VN6Q_Manual.pdf
