Photoelectric Sensor, OS10-Series, Diffused with BGS, Red beam, Operating range 6...350 mm, PNP, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 400 Hz, IP67, M8 4-pin connector

OS10-AK350CP6Q8

SKU OS10-AK350CP6Q8
by ELCO Industrial Automation

Photoelectric Sensor, OS10-Series, Diffused with BGS, Red beam, Operating range 6...350 mm, PNP, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 400 Hz, IP67, M8 4-pin connector

$47.71 - $47.71
$47.71
$47.71 - $47.71
$47.71
Availability:
In stock

Photoelectric Sensor, OS10-Series, Diffused with BGS, Red beam, Operating range 6...350 mm, PNP, L.O / D.O, 10…30V DC, -25…55°C, Switching frequency 400 Hz, IP67, M8 4-pin connector

Specifications

Connection type M8, 4-pin
Switching frequency 400 Hz
Supply voltage 10 ... 30 V DC
Load current ≤ 100 mA
Ambient temperature -25 … +55 ℃
Light source Red LED
Spot size 30 mm @ 350 mm
Output type PNP
Output status L.O / D.O
Detection method BGS Diffused
Sensing range 6 … 350 mm
IP rating IP67

No additional information at this time.

Downloads

CE ELCO_OS10_CE.pdf
Datasheet ELCO_OS10_DataSheet_EN.pdf
Datasheet ELCO_OS10_DataSheet_CN.pdf
3D Drawing ELCO_OS10-AK350CP6Q8.stp
Manual ELCO_OS10-AK350CP6Q8_Manual.pdf
