GZMB4 Plug-In Relay Socket for R4 Series

Standard Features

  • Plug-in relay socket designed for R-series industrial relays
  • Spring terminal connections for secure and reliable wiring
  • Suitable for 35 mm DIN rail mounting applications
  • Rated up to 10 A, 300 V AC
  • Four-pole configuration
  • Accepts wire sizes from 24–16 AWG (0.2–1.5 mm²)

Specifications

Part Number GZMB4
Rated Voltage 300 V AC
Compatible Relay Series R4
Terminal Type Spring terminals
Mounting Type 35 mm DIN Rail Mount
DIN Rail Standard PN-EN 60715
Dimensions (accessory) 95 × 31 × 42.5 (80) mm
Number of Poles 4
Contact Rating 10A
Max. Cable Cross Section 1 × 0.2–1.5 mm²
Wire Size (AWG) 24–16 AWG
Stripping Length 9–11 mm
Standard Pack 10
