Fieldbus I/O Module Compact67, Multiprotocol PROFINET / EtherNet/IP, 16 DI/DO, PNP, 8 x M12 A-code 5-pin, 2 x M12 D-code 4-pin, 2 x 7/8“ 4-pin, 24 V DC, Metal housing, IP67

Specifications

Number of channels 16 DI/DO
Communication protocol EtherNet/IP
IP rating IP67
Power connection 2 x 7/8" 4-pin
Fieldbus connection 2 x M12 D-Code
Power supply 18 ... 30 V DC
Input type PNP
Output type PNP
Dimensions 60 x 230 x 37.8 mm
Ambient temperature -25 ... +70 °C
Storage temperature -40 ...

No additional information at this time.

Downloads

CE ELCO_Compact67_02_CE.pdf
MTTF MTTF_AD_FCEN-16UP-MP4_V1.0_EN.pdf
Datasheet ELCO_FCEN_16UP_MP4_Datasheet_CN.pdf
Datasheet DS_AD_FCEN_16UP_MP4_V1.0_EN.pdf
3D Drawing CAD_AD_Compact67-EN-MP4_V1.0.stp
EPLAN Drawing ELCO.FCEN-16UP-MP4.edz
Manual UM_AD_FCEN-16UP-MP4_V1.0_EN.pdf
Manual ELCO_FCEN_16UP_MP4_Manual_CN.pdf
Configuration file EDS_FCEN-16UP-MP4_V1.0.3.zip
